17.3" AU Optronics LED LCD Screen B173RTN02.2 1600x900 30-pin matte
Specifications
Specifications
| Connector | 30-pin |
| Display Technology | LED LCD |
| Custom Bundle | No |
| Screen Finish | Matt |
| Screen Size | 17.3 in |
| MPN | B173RTN02.2 |
| Brand | AU Optronics |
| Type | TFT-LCD |
| Maximum Resolution | 1600 x 900 |
| Compatible Brand | Universal |
| Modified Item | No |
| Aspect Ratio | 16:9 |
| Non-Domestic Product | No |
Product Description
- Brand
- AUO
- Model P/N
- B173RTN02.2
- Diagonal Size
- 17.3"
- Panel Type
- a-Si TFT-LCD, LCM
- Resolution
- 1600(RGB)×900, HD+ 106PPI
- Pixel Format
- RGB Vertical Stripe
- Active Area
- 382.08(W)×214.92(H) mm
- Bezel Opening
- -
| Outline(mm) |
|---|
| Luminance |
| Viewing Angle |
| Good View at |
| Color Depth |
| Outline Shape |
| Refresh Rate |
| 398.1(W)×250.5(H)×4(D) |
| 220 (Typ.)(cd/m²) |
| 45/45/15/35 (Typ.)(CR≥10) |
| 6 o'clock |
| 262K 60% NTSC |
| Flat (PCBA Flat, T3.4~4.0mm) |
| 60Hz |
| Treatment |
| Contrast Ratio |
| Work Mode |
| Response |
| Backlight |
| Used for |
| Touchscreen |
| Glare (Haze 0%), Hard coating (3H) |
| 500 : 1 (Typ.) (TM) |
| TN, Normally White, Transmissive |
| 8 (Typ.)(Tr+Td) ms |
| WLED , 10K hours , With LED Driver |
| Without |
| Signal Type | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
|---|---|
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
