Technical Information

Number of Screens

• 1

Viewable Screen Size

• 27"

Screen Mode

• Full HD

Panel Technology

• Vertical Alignment (VA)

Response Time

• 1 ms

Aspect Ratio

• 16:9

Pixel Pitch

• 0.31 mm

Vertical Viewing Angle

• 178°

Backlight Technology

• LED

Mount Type

• Wall Mountable

Horizontal Frequency

• 31 kHz to 84.50 kHz - VGA
• 31 kHz to 112.50 kHz - HDMI 1.4

Vertical Frequency

• 75 Hz
• 48 Hz to 100 Hz - HDMI 1.4

Screen Size Class

• 27"

Tilt Angle

• -5° to 15°

Adjustable Display Pivot

• No

Active Display Area (mm)

• 598x336

Frequency (Horizontal/Vertical)

• VGA:31KHz-84.3KHz/75Hz
• HDMI 1.4:31KHz-112.5KHz/48Hz-100Hz

Physical Characteristics

VESA Mount Compatible

• Yes

VESA Mount Standard

• 75 x 75

Colour

• Black

Height

• 363 mm

Width

• 614 mm

Depth

• 47 mm

Height with Stand

• 452 mm

Width with Stand

• 614 mm

Depth with Stand

• 224 mm

Video

Maximum Resolution

• 1920 x 1080

Standard Refresh Rate

• 75 Hz

Colour Supported

• 16.7 Million Colours

Colour Depth

• 6-bit+FRC

Dynamic Contrast Ratio

• 100,000,000:1

Brightness

• 250 cd/m²

Color Gamut

• 72% NTSC

Native Contrast Ratio

• 3,000:1

Miscellaneous

Package Contents

• 1 x SB272  Widescreen LCD Monitor
• 1 x HDMI Cable
• 1 x Power Cord (Australia)

Interfaces/Ports

HDMI

• Yes

HDMI Version

• 1.4

VGA

• Yes

Power Description

Standby Power Consumption (Energy Star)

• 500 mW

Off-Mode Power Consumption (Energy Star)

• 300 mW

Maximum Power Consumption (Energy Star)

• 36 W

Operating Power Consumption (Energy Star)

• 24 W
