Supermicro MBD-X10SRA-O socket 2011-v3 Acer Veriton P330 F3 m/b SB.RAL11.001
Specifications
Specifications
| Socket Type | LGA 2011-v3 |
| Compatible CPU Brand | Intel |
| Number of Memory Slots | 8 |
Product Description
Technical Specifications for MBD-X10SRA-O
| General Information | |
| Manufacturer Part Number | MBD-X10SRA-O |
| Brand Name | Supermicro |
| Product Type | Server Motherboard |
| Processor & Chipset | |
| Chipset Manufacturer | Intel |
| Total Processor Supported | 1 |
| Processor Socket | Socket LGA 2011-v3 |
| Processor Supported | Xeon |
| Memory | |
| Number of Memory Slots | 8 |
| Memory Form Factor | DIMM LRDIMM UDIMM |
| Maximum Memory | 512 GB |
| Memory Speed Supported | 2.13 GHz 1.87 GHz 1.60 GHz |
| Memory Technology | DDR4 SDRAM |
| I/O Controller | |
| Controller Type | Serial ATA/600 |
| Audio | |
| Audio Channels | 7.1 |
| Network & Communication | |
| Gigabit Ethernet | Yes |
| I/O Expansions | |
| Number of Total Expansion Slots | 6 |
| Total Number of PCI Express Slots | 6 |
| Number of PCI Express x1 Slots | 2 |
| Number of PCI Express x16 Slots | 4 |
| Interfaces/Ports | |
| Total Number of USB Ports | 6 |
| Number of USB 3.0 Ports | 6 |
| Onboard Interfaces | |
| Number of SATA Interfaces | 10 |
| Total Number of Onboard USB Ports | 2 |
| Number of Onboard USB 3.0 Ports | 2 |
| Physical Characteristics | |
| Form Factor | ATX |
| Width | 12" |
| Depth | 9.6" |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Certification | RoHS |
